70-persistent-net.rulesがないぞ・・・

XenServer上にCentOS6.3をインストールした。

IPアドレスを変更して、ネットワークを再起動したらエラーが発生。
あぁ、/etc/udev/rules.d/70-persistent-net.rulesを変更を忘れてた。
変更しないと思ったら、ファイルがない・・・ファイルがない・・。



#cat /etc/sysconfig/network-scripts/ifcfg-eth0 DEVICE="eth0" BOOTPROTO="static" #HWADDR="B2:49:F5:A7:B4:A6" NM_CONTROLLED="no" ONBOOT="yes" TYPE="Ethernet" UUID="28fc6cb4-1586-416e-a975-8ea6b7fe26b6" IPADDR=192.168.0.100 NETMASK=255.255.255.0 GATEWAY=192.168.0.1
/etc/sysconfig/network-scripts/network-functions
 →get_hwaddr()で、/sys/class/net/${1}/addressからMacマックアドレスを参照してるのね・・・


/etc/sysconfig/network-scripts/ifup-eth
→で、HWADDRと一致してなかったら、Device ${DEVICE} has different MAC address than expected, ignoring
　のエラーを吐き出すと・・・

というわけで、HWADDRの設定をコメントアウトするのが一番手っ取り早い対応なのかな・・・

70-persistent-net.rulesをないのは、なんでなんだろう。

netsnmpにMIBを追加,ESXi5.0のsnmpポーリング

netsnmpにESXi5.0に拡張mibを読み込ます。すべてはどこまで監視できるのか確認する為。

と、いうわけでnetsnmp拡張フォルダを格納フォルダは以下の通り。

[root@localhost mibs]# pwd
/usr/share/snmp/mibs

MIBのDownloadは、こちらから。
http://communities.vmware.com/community/vmtn/developer/forums/managementapi

 サイトのコンテンツ中央くらいに、『SNMP MIB Modules』が表示されているので、ここからDownloadする。（My VMwareのアカウントの入力を要求されるから、用意しておく。別にダウンロードの際に登録してもよい。）

↓

DownloadしたMIB(zip)を、展開してnetsnmpのフォルダへおいておく。


で、snmpコマンドを読み込む際にMIBを追加で読み込むように、snmp.confに設定行を追加しておく。 notifications.txtはドキュメントみたいなので、間違わないように・・・。まぁ一覧みたいなので一読しておくのも悪くないかも。

[root@localhost mibs]# mkdir -p /root/.snmp/
[root@localhost mibs]# vi /root/.snmp/snmp.conf
追加行は以下の通り
mibs +/usr/share/snmp/mibs/HOST-RESOURCES-MIB.mib
mibs +/usr/share/snmp/mibs/HOST-RESOURCES-TYPES.mib
mibs +/usr/share/snmp/mibs/IF-MIB.mib
mibs +/usr/share/snmp/mibs/SNMPv2-CONF.mib
mibs +/usr/share/snmp/mibs/SNMPv2-MIB.mib
mibs +/usr/share/snmp/mibs/SNMPv2-SMI.mib
mibs +/usr/share/snmp/mibs/SNMPv2-TC.mib
mibs +/usr/share/snmp/mibs/VMWARE-AGENTCAP-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-CIMOM-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-ENV-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-OBSOLETE-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-PRODUCTS-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-RESOURCES-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-ROOT-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-SYSTEM-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-TC-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-VC-EVENT-MIB.mib
mibs +/usr/share/snmp/mibs/VMWARE-VMINFO-MIB.mib

snmpwalkでEnterpriseOID配下（.1.3.6.1.4.1.6876）を参照してみる。

[root@localhost mibs]snmpwalk -v 1 -c public 192.168.230.2 .1.3.6.1.4.1.6876
VMWARE-SYSTEM-MIB::vmwProdName.0 = STRING: VMware ESXi
VMWARE-SYSTEM-MIB::vmwProdVersion.0 = STRING: 5.0.0
VMWARE-SYSTEM-MIB::vmwProdBuild.0 = STRING: 469512
VMWARE-SYSTEM-MIB::vmwProdUpdate.0 = STRING: 0
VMWARE-SYSTEM-MIB::vmwProdPatch.0 = STRING: 0
VMWARE-VMINFO-MIB::vmwVmDisplayName.7 = STRING: snmp01
VMWARE-VMINFO-MIB::vmwVmDisplayName.8 = STRING: zabbix
VMWARE-VMINFO-MIB::vmwVmDisplayName.13 = STRING: snmp02
VMWARE-VMINFO-MIB::vmwVmDisplayName.14 = STRING: vCenter
VMWARE-VMINFO-MIB::vmwVmDisplayName.17 = STRING: web
VMWARE-VMINFO-MIB::vmwVmConfigFile.7 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c/ZABBIX/ZABBIX.vmx
VMWARE-VMINFO-MIB::vmwVmConfigFile.8 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c/CentOS6_x86_64/CentOS6_x86_64.vmx
VMWARE-VMINFO-MIB::vmwVmConfigFile.13 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c/KVM1/KVM1.vmx
VMWARE-VMINFO-MIB::vmwVmConfigFile.14 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c/4_vCenter/4_vCenter.vmx
VMWARE-VMINFO-MIB::vmwVmConfigFile.17 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c/websvr01/websvr01.vmx
VMWARE-VMINFO-MIB::vmwVmGuestOS.7 = STRING: Linux 2.6.32-220.el6.x86_64 CentOS release 6.2 (Final)
VMWARE-VMINFO-MIB::vmwVmGuestOS.8 = STRING: Linux 2.6.32-71.el6.x86_64 CentOS Linux release 6.0 (Final)
VMWARE-VMINFO-MIB::vmwVmGuestOS.13 = STRING: Linux 2.6.32-71.el6.x86_64 CentOS Linux release 6.0 (Final)
VMWARE-VMINFO-MIB::vmwVmGuestOS.14 = STRING: Windows Server 2008 R2 Standard Edition, 64-bit  (Build 7600)
VMWARE-VMINFO-MIB::vmwVmGuestOS.17 = STRING: Linux 2.6.32-71.el6.x86_64 CentOS Linux release 6.0 (Final)
VMWARE-VMINFO-MIB::vmwVmMemSize.7 = INTEGER: 2048 megabytes
VMWARE-VMINFO-MIB::vmwVmMemSize.8 = INTEGER: 2048 megabytes
VMWARE-VMINFO-MIB::vmwVmMemSize.13 = INTEGER: 2048 megabytes
VMWARE-VMINFO-MIB::vmwVmMemSize.14 = INTEGER: 4096 megabytes
VMWARE-VMINFO-MIB::vmwVmMemSize.17 = INTEGER: 2048 megabytes
VMWARE-VMINFO-MIB::vmwVmState.7 = STRING: poweredOn
VMWARE-VMINFO-MIB::vmwVmState.8 = STRING: poweredOn
VMWARE-VMINFO-MIB::vmwVmState.13 = STRING: poweredOn
VMWARE-VMINFO-MIB::vmwVmState.14 = STRING: poweredOn
VMWARE-VMINFO-MIB::vmwVmState.17 = STRING: poweredOn
VMWARE-VMINFO-MIB::vmwVmVMID.7 = INTEGER: 7
VMWARE-VMINFO-MIB::vmwVmVMID.8 = INTEGER: 8
VMWARE-VMINFO-MIB::vmwVmVMID.13 = INTEGER: 13
VMWARE-VMINFO-MIB::vmwVmVMID.14 = INTEGER: 14
VMWARE-VMINFO-MIB::vmwVmVMID.17 = INTEGER: 17
VMWARE-VMINFO-MIB::vmwVmGuestState.7 = STRING: running
VMWARE-VMINFO-MIB::vmwVmGuestState.8 = STRING: running
VMWARE-VMINFO-MIB::vmwVmGuestState.13 = STRING: running
VMWARE-VMINFO-MIB::vmwVmGuestState.14 = STRING: running
VMWARE-VMINFO-MIB::vmwVmGuestState.17 = STRING: running
VMWARE-VMINFO-MIB::vmwVmCpus.7 = INTEGER: 1
VMWARE-VMINFO-MIB::vmwVmCpus.8 = INTEGER: 1
VMWARE-VMINFO-MIB::vmwVmCpus.13 = INTEGER: 1
VMWARE-VMINFO-MIB::vmwVmCpus.14 = INTEGER: 1
VMWARE-VMINFO-MIB::vmwVmCpus.17 = INTEGER: 1
VMWARE-VMINFO-MIB::vmwVmUUID.7 = STRING: "4209ca78-10b3-a89b-08cb-9adee32f5a09"
VMWARE-VMINFO-MIB::vmwVmUUID.8 = STRING: "4209bcde-70bd-6022-5d3f-1114f1f9b544"
VMWARE-VMINFO-MIB::vmwVmUUID.13 = STRING: "420c11e5-efd5-9bfb-f593-a1dc223237a9"
VMWARE-VMINFO-MIB::vmwVmUUID.14 = STRING: "564d28df-9abc-e957-c5f2-42e6a67f00c4"
VMWARE-VMINFO-MIB::vmwVmUUID.17 = STRING: "4226b56c-98db-6437-e81b-6e8593f7f122"
VMWARE-VMINFO-MIB::vmwHbaNum.7.1000 = STRING: SCSI Controller 0
VMWARE-VMINFO-MIB::vmwHbaNum.8.1000 = STRING: SCSI Controller 0
VMWARE-VMINFO-MIB::vmwHbaNum.13.1000 = STRING: SCSI Controller 0
VMWARE-VMINFO-MIB::vmwHbaNum.14.1000 = STRING: SCSI Controller 0
VMWARE-VMINFO-MIB::vmwHbaNum.17.1000 = STRING: SCSI Controller 0
VMWARE-VMINFO-MIB::vmwHbaVirtDev.7.1000 = STRING: lsilogic
VMWARE-VMINFO-MIB::vmwHbaVirtDev.8.1000 = STRING: lsilogic
VMWARE-VMINFO-MIB::vmwHbaVirtDev.13.1000 = STRING: lsilogic
VMWARE-VMINFO-MIB::vmwHbaVirtDev.14.1000 = STRING: lsisas1068
VMWARE-VMINFO-MIB::vmwHbaVirtDev.17.1000 = STRING: lsilogic
VMWARE-VMINFO-MIB::vmwHbaTgtNum.7.2000 = STRING: Hard Disk 1
VMWARE-VMINFO-MIB::vmwHbaTgtNum.8.2000 = STRING: Hard Disk 1
VMWARE-VMINFO-MIB::vmwHbaTgtNum.13.2000 = STRING: Hard Disk 1
VMWARE-VMINFO-MIB::vmwHbaTgtNum.14.2000 = STRING: Hard Disk 1
VMWARE-VMINFO-MIB::vmwHbaTgtNum.17.2000 = STRING: Hard Disk 1
VMWARE-VMINFO-MIB::vmwVmNetNum.7.4000 = STRING: Ethernet 1
VMWARE-VMINFO-MIB::vmwVmNetNum.8.4000 = STRING: Ethernet 1
VMWARE-VMINFO-MIB::vmwVmNetNum.13.4000 = STRING: Ethernet 1
VMWARE-VMINFO-MIB::vmwVmNetNum.14.4000 = STRING: Ethernet 1
VMWARE-VMINFO-MIB::vmwVmNetNum.17.4000 = STRING: Ethernet 1
VMWARE-VMINFO-MIB::vmwVmNetName.7.4000 = STRING: VM Network
VMWARE-VMINFO-MIB::vmwVmNetName.8.4000 = STRING: VM Network
VMWARE-VMINFO-MIB::vmwVmNetName.13.4000 = STRING: VM Network
VMWARE-VMINFO-MIB::vmwVmNetName.14.4000 = STRING: VM Network
VMWARE-VMINFO-MIB::vmwVmNetName.17.4000 = STRING: VM Network
VMWARE-VMINFO-MIB::vmwVmNetConnType.7.4000 = STRING: monitor_dev
VMWARE-VMINFO-MIB::vmwVmNetConnType.8.4000 = STRING: monitor_dev
VMWARE-VMINFO-MIB::vmwVmNetConnType.13.4000 = STRING: monitor_dev
VMWARE-VMINFO-MIB::vmwVmNetConnType.14.4000 = STRING: monitor_dev
VMWARE-VMINFO-MIB::vmwVmNetConnType.17.4000 = STRING: monitor_dev
VMWARE-VMINFO-MIB::vmwVmNetConnected.7.4000 = STRING: true
VMWARE-VMINFO-MIB::vmwVmNetConnected.8.4000 = STRING: true
VMWARE-VMINFO-MIB::vmwVmNetConnected.13.4000 = STRING: true
VMWARE-VMINFO-MIB::vmwVmNetConnected.14.4000 = STRING: true
VMWARE-VMINFO-MIB::vmwVmNetConnected.17.4000 = STRING: true
VMWARE-VMINFO-MIB::vmwVmMAC.7.4000 = STRING: 0:50:56:89:75:14
VMWARE-VMINFO-MIB::vmwVmMAC.8.4000 = STRING: 0:50:56:89:75:13
VMWARE-VMINFO-MIB::vmwVmMAC.13.4000 = STRING: 0:50:56:8c:7a:50
VMWARE-VMINFO-MIB::vmwVmMAC.14.4000 = STRING: 0:c:29:7f:0:c4
VMWARE-VMINFO-MIB::vmwVmMAC.17.4000 = STRING: 0:50:56:a6:55:67
VMWARE-VMINFO-MIB::vmwFdName.7.8000 = STRING: W: VM configured to use client device
VMWARE-VMINFO-MIB::vmwFdName.8.8000 = STRING: W: VM configured to use client device
VMWARE-VMINFO-MIB::vmwFdName.13.8000 = STRING: W: VM configured to use client device
VMWARE-VMINFO-MIB::vmwFdName.14.8000 = STRING: W: VM configured to use client device
VMWARE-VMINFO-MIB::vmwFdName.17.8000 = STRING: W: VM configured to use client device
VMWARE-VMINFO-MIB::vmwFdConnected.7.8000 = STRING: false
VMWARE-VMINFO-MIB::vmwFdConnected.8.8000 = STRING: false
VMWARE-VMINFO-MIB::vmwFdConnected.13.8000 = STRING: false
VMWARE-VMINFO-MIB::vmwFdConnected.14.8000 = STRING: false
VMWARE-VMINFO-MIB::vmwFdConnected.17.8000 = STRING: false
VMWARE-VMINFO-MIB::vmwCdromName.7.3002 = STRING: [datastore2] iso/CentOS-6.0-x86_64-bin-DVD2.iso
VMWARE-VMINFO-MIB::vmwCdromName.8.3002 = STRING: [] /usr/lib/vmware/isoimages/linux.iso
VMWARE-VMINFO-MIB::vmwCdromName.13.3002 = STRING: [datastore2] iso/CentOS-6.0-x86_64-bin-DVD1.iso
VMWARE-VMINFO-MIB::vmwCdromName.14.3002 = STRING: [datastore2] iso/ja_office_visio_professional_2007_cd_x12-19332.iso
VMWARE-VMINFO-MIB::vmwCdromName.17.3002 = STRING: [] /usr/lib/vmware/isoimages/linux.iso
VMWARE-VMINFO-MIB::vmwCdromConnected.7.3002 = STRING: false
VMWARE-VMINFO-MIB::vmwCdromConnected.8.3002 = STRING: false
VMWARE-VMINFO-MIB::vmwCdromConnected.13.3002 = STRING: false
VMWARE-VMINFO-MIB::vmwCdromConnected.14.3002 = STRING: false
VMWARE-VMINFO-MIB::vmwCdromConnected.17.3002 = STRING: false
VMWARE-RESOURCES-MIB::vmwNumCPUs.0 = Gauge32: 1
VMWARE-RESOURCES-MIB::vmwMemSize.0 = Gauge32: 33469556 kilobytes
VMWARE-RESOURCES-MIB::vmwMemCOS.0 = Gauge32: 0 kilobytes
VMWARE-RESOURCES-MIB::vmwMemAvail.0 = Gauge32: 33469556 kilobytes
VMWARE-RESOURCES-MIB::vmwHostBusAdapterNumber.0 = INTEGER: 4
VMWARE-RESOURCES-MIB::vmwHbaDeviceName.1 = STRING: vmhba0
VMWARE-RESOURCES-MIB::vmwHbaDeviceName.2 = STRING: vmhba1
VMWARE-RESOURCES-MIB::vmwHbaDeviceName.3 = STRING: vmhba33
VMWARE-RESOURCES-MIB::vmwHbaDeviceName.4 = STRING: vmhba34
VMWARE-RESOURCES-MIB::vmwHbaBusNumber.1 = INTEGER: 0
VMWARE-RESOURCES-MIB::vmwHbaBusNumber.2 = INTEGER: 0
VMWARE-RESOURCES-MIB::vmwHbaBusNumber.3 = INTEGER: 0
VMWARE-RESOURCES-MIB::vmwHbaBusNumber.4 = INTEGER: 0
VMWARE-RESOURCES-MIB::vmwHbaStatus.1 = INTEGER: unknown(1)
VMWARE-RESOURCES-MIB::vmwHbaStatus.2 = INTEGER: unknown(1)
VMWARE-RESOURCES-MIB::vmwHbaStatus.3 = INTEGER: unknown(1)
VMWARE-RESOURCES-MIB::vmwHbaStatus.4 = INTEGER: unknown(1)
VMWARE-RESOURCES-MIB::vmwHbaModelName.1 = STRING: Cougar Point 4 port SATA IDE Controller
VMWARE-RESOURCES-MIB::vmwHbaModelName.2 = STRING: Cougar Point 2 port SATA IDE Controller
VMWARE-RESOURCES-MIB::vmwHbaModelName.3 = STRING: Cougar Point 4 port SATA IDE Controller
VMWARE-RESOURCES-MIB::vmwHbaModelName.4 = STRING: Cougar Point 2 port SATA IDE Controller
VMWARE-RESOURCES-MIB::vmwHbaDriverName.1 = STRING: ata_piix
VMWARE-RESOURCES-MIB::vmwHbaDriverName.2 = STRING: ata_piix
VMWARE-RESOURCES-MIB::vmwHbaDriverName.3 = STRING: ata_piix
VMWARE-RESOURCES-MIB::vmwHbaDriverName.4 = STRING: ata_piix
VMWARE-RESOURCES-MIB::vmwHbaPci.1 = STRING: 00:1f.2
VMWARE-RESOURCES-MIB::vmwHbaPci.2 = STRING: 00:1f.5
VMWARE-RESOURCES-MIB::vmwHbaPci.3 = STRING: 00:1f.2
VMWARE-RESOURCES-MIB::vmwHbaPci.4 = STRING: 00:1f.5
VMWARE-ENV-MIB::vmwEnvSource.0 = INTEGER: indications(3)
VMWARE-ENV-MIB::vmwEnvInIndications.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvLastIn.0 = Timeticks: (0) 0:00:00.00
VMWARE-ENV-MIB::vmwEnvOutNotifications.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvInErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvIndOidErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvCvtValueErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvCvtSyntaxErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvCvtOidErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvGetClassErrs.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvPropertySkips.0 = Counter32: 0
VMWARE-ENV-MIB::vmwEnvIndicationSkips.0 = Counter32: 0

拡張MIB（6876）配下しかsnmpwalkをかけていないが、リソース（論理CPU、メモリ等）の割り当て状態くらいだったら、わかるけど そのほかの値は、あまり有用なものはなかったなってことくらいかもしれない。 あ、でも仮想マシンのPower状態やGuestの稼働（Running）くらいだったら見えるからまぁいいかもしれない。 で、実はダウンロードしてきたMIBには実はもっとたくさんのMIB定義ファイルがあったから実はもっと色々見えるんだろうな・・ って勝手に思っている。実際mib-2配下includeしているし、まぁ試しに見てみるかと思ったらそれらしいものが、たくさん見えたが MIBファイルの内容までは確認できていない。

[root@localhost ~]#snmpwalk -v 1 -c public 192.168.230.2 .1.3.6.1.2.1
SNMPv2-MIB::sysDescr.0 = STRING: VMware ESX 5.0.0 build-469512 VMware, Inc. x86_64
SNMPv2-MIB::sysObjectID.0 = OID: VMWARE-PRODUCTS-MIB::vmwESX
DISMAN-EVENT-MIB::sysUpTimeInstance = Timeticks: (128094798) 14 days, 19:49:07.98
SNMPv2-MIB::sysContact.0 = STRING: not set
SNMPv2-MIB::sysName.0 = STRING: esxi02
SNMPv2-MIB::sysLocation.0 = STRING: not set
SNMPv2-MIB::sysServices.0 = INTEGER: 72
SNMPv2-MIB::sysORLastChange.0 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORID.1 = OID: SNMPv2-MIB::snmpMIB
SNMPv2-MIB::sysORID.2 = OID: IF-MIB::ifMIB
SNMPv2-MIB::sysORID.3 = OID: HOST-RESOURCES-MIB::hostResourcesMibModule
SNMPv2-MIB::sysORID.4 = OID: VMWARE-SYSTEM-MIB::vmwSystemMIB
SNMPv2-MIB::sysORID.5 = OID: VMWARE-VMINFO-MIB::vmwVmInfoMIB
SNMPv2-MIB::sysORID.6 = OID: VMWARE-RESOURCES-MIB::vmwResourcesMIB
SNMPv2-MIB::sysORID.7 = OID: VMWARE-ENV-MIB::vmwEnv
SNMPv2-MIB::sysORDescr.1 = STRING: SNMPv2-MIB, RFC 3418
SNMPv2-MIB::sysORDescr.2 = STRING: IF-MIB, RFC 2863
SNMPv2-MIB::sysORDescr.3 = STRING: HOST-RESOURCES-MIB, RFC 2790
SNMPv2-MIB::sysORDescr.4 = STRING: VMWARE-SYSTEM-MIB, REVISION 201008020000Z
SNMPv2-MIB::sysORDescr.5 = STRING: VMWARE-VMINFO-MIB, REVISION 201006220000Z
SNMPv2-MIB::sysORDescr.6 = STRING: VMWARE-RESOURCES-MIB, REVISION 200810150000Z
SNMPv2-MIB::sysORDescr.7 = STRING: VMWARE-ENV-MIB, REVISION 201005120000Z
SNMPv2-MIB::sysORUpTime.1 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.2 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.3 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.4 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.5 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.6 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORUpTime.7 = Timeticks: (0) 0:00:00.00
IF-MIB::ifNumber.0 = INTEGER: 1
IF-MIB::ifIndex.1 = INTEGER: 1
IF-MIB::ifDescr.1 = STRING: Device vmnic0 at 02:00.0 r8168
IF-MIB::ifType.1 = INTEGER: ethernetCsmacd(6)
IF-MIB::ifMtu.1 = INTEGER: 1500
IF-MIB::ifSpeed.1 = Gauge32: 1000000000
IF-MIB::ifPhysAddress.1 = STRING: 50:e5:49:44:9f:2c
IF-MIB::ifAdminStatus.1 = INTEGER: up(1)
IF-MIB::ifOperStatus.1 = INTEGER: up(1)
IF-MIB::ifLastChange.1 = Timeticks: (0) 0:00:00.00
IF-MIB::ifInOctets.1 = Counter32: 3527229789
IF-MIB::ifInUcastPkts.1 = Counter32: 40699475
IF-MIB::ifInNUcastPkts.1 = Counter32: 424819
IF-MIB::ifInDiscards.1 = Counter32: 0
IF-MIB::ifInErrors.1 = Counter32: 0
IF-MIB::ifInUnknownProtos.1 = Counter32: 0
IF-MIB::ifOutOctets.1 = Counter32: 3698549733
IF-MIB::ifOutUcastPkts.1 = Counter32: 41756122
IF-MIB::ifOutNUcastPkts.1 = Counter32: 1425436
IF-MIB::ifOutDiscards.1 = Counter32: 0
IF-MIB::ifOutErrors.1 = Counter32: 0
IF-MIB::ifOutQLen.1 = Gauge32: 0
IF-MIB::ifSpecific.1 = OID: SNMPv2-SMI::zeroDotZero
SNMPv2-MIB::snmpInPkts.0 = Counter32: 16292
SNMPv2-MIB::snmpOutPkts.0 = Counter32: 16292
SNMPv2-MIB::snmpInBadVersions.0 = Counter32: 0
SNMPv2-MIB::snmpInBadCommunityNames.0 = Counter32: 0
SNMPv2-MIB::snmpInBadCommunityUses.0 = Counter32: 0
SNMPv2-MIB::snmpInASNParseErrs.0 = Counter32: 0
SNMPv2-MIB::snmpInTotalReqVars.0 = Counter32: 16286
SNMPv2-MIB::snmpInGetRequests.0 = Counter32: 442
SNMPv2-MIB::snmpInGetNexts.0 = Counter32: 15858
SNMPv2-MIB::snmpInSetRequests.0 = Counter32: 0
SNMPv2-MIB::snmpOutTooBigs.0 = Counter32: 0
SNMPv2-MIB::snmpOutNoSuchNames.0 = Counter32: 11
SNMPv2-MIB::snmpOutBadValues.0 = Counter32: 0
SNMPv2-MIB::snmpOutGenErrs.0 = Counter32: 0
SNMPv2-MIB::snmpOutTraps.0 = Counter32: 112
SNMPv2-MIB::snmpEnableAuthenTraps.0 = INTEGER: disabled(2)
SNMPv2-MIB::snmpSilentDrops.0 = Counter32: 0
SNMPv2-MIB::snmpProxyDrops.0 = Counter32: 0
HOST-RESOURCES-MIB::hrSystemUptime.0 = Timeticks: (137350200) 15 days, 21:31:42.00
HOST-RESOURCES-MIB::hrSystemDate.0 = STRING: 2012-4-27,11:58:16.0
HOST-RESOURCES-MIB::hrSystemInitialLoadDevice.0 = INTEGER: 12
HOST-RESOURCES-MIB::hrSystemInitialLoadParameters.0 = STRING: "/b.b00 vmbTbootEnabled=false tboot=0x0x101a000 no-auto-partition bootUUID=7271fdd489cf870cfd9bf43d2230a99d"
HOST-RESOURCES-MIB::hrSystemNumUsers.0 = Gauge32: 2
HOST-RESOURCES-MIB::hrSystemProcesses.0 = Gauge32: 49
HOST-RESOURCES-MIB::hrSystemMaxProcesses.0 = INTEGER: 2048
HOST-RESOURCES-MIB::hrMemorySize.0 = INTEGER: 33469556 KBytes
HOST-RESOURCES-MIB::hrStorageIndex.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrStorageIndex.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrStorageIndex.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrStorageIndex.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrStorageIndex.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrStorageIndex.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrStorageType.1 = OID: HOST-RESOURCES-TYPES::hrStorageFixedDisk
HOST-RESOURCES-MIB::hrStorageType.2 = OID: HOST-RESOURCES-TYPES::hrStorageFixedDisk
HOST-RESOURCES-MIB::hrStorageType.3 = OID: HOST-RESOURCES-TYPES::hrStorageRamDisk
HOST-RESOURCES-MIB::hrStorageType.4 = OID: HOST-RESOURCES-TYPES::hrStorageRamDisk
HOST-RESOURCES-MIB::hrStorageType.5 = OID: HOST-RESOURCES-TYPES::hrStorageRamDisk
HOST-RESOURCES-MIB::hrStorageType.6 = OID: HOST-RESOURCES-TYPES::hrStorageRamDisk
HOST-RESOURCES-MIB::hrStorageDescr.1 = STRING: /vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c
HOST-RESOURCES-MIB::hrStorageDescr.2 = STRING: /vmfs/volumes/4f02074e-7a4bdd3e-3cff-50e549449f2c
HOST-RESOURCES-MIB::hrStorageDescr.3 = STRING: /vmfs/volumes/4f52cebb-110a01fa-9d24-50e549449f2c
HOST-RESOURCES-MIB::hrStorageDescr.4 = STRING: /vmfs/volumes/d4fd7172-0c87cf89-9bfd-f43d2230a99d
HOST-RESOURCES-MIB::hrStorageDescr.5 = STRING: /vmfs/volumes/a3b3107c-1e04eddb-4569-107ff98f985c
HOST-RESOURCES-MIB::hrStorageDescr.6 = STRING: /vmfs/volumes/4f52ceb4-b12cef1c-ff29-50e549449f2c
HOST-RESOURCES-MIB::hrStorageAllocationUnits.1 = INTEGER: 1048576 Bytes
HOST-RESOURCES-MIB::hrStorageAllocationUnits.2 = INTEGER: 1048576 Bytes
HOST-RESOURCES-MIB::hrStorageAllocationUnits.3 = INTEGER: 65536 Bytes
HOST-RESOURCES-MIB::hrStorageAllocationUnits.4 = INTEGER: 4096 Bytes
HOST-RESOURCES-MIB::hrStorageAllocationUnits.5 = INTEGER: 4096 Bytes
HOST-RESOURCES-MIB::hrStorageAllocationUnits.6 = INTEGER: 8192 Bytes
HOST-RESOURCES-MIB::hrStorageSize.1 = INTEGER: 476672
HOST-RESOURCES-MIB::hrStorageSize.2 = INTEGER: 116992
HOST-RESOURCES-MIB::hrStorageSize.3 = INTEGER: 65515
HOST-RESOURCES-MIB::hrStorageSize.4 = INTEGER: 63929
HOST-RESOURCES-MIB::hrStorageSize.5 = INTEGER: 63929
HOST-RESOURCES-MIB::hrStorageSize.6 = INTEGER: 36586
HOST-RESOURCES-MIB::hrStorageUsed.1 = INTEGER: 82412
HOST-RESOURCES-MIB::hrStorageUsed.2 = INTEGER: 8663
HOST-RESOURCES-MIB::hrStorageUsed.3 = INTEGER: 418
HOST-RESOURCES-MIB::hrStorageUsed.4 = INTEGER: 32624
HOST-RESOURCES-MIB::hrStorageUsed.5 = INTEGER: 2
HOST-RESOURCES-MIB::hrStorageUsed.6 = INTEGER: 22551
HOST-RESOURCES-MIB::hrStorageAllocationFailures.1 = Counter32: 0
HOST-RESOURCES-MIB::hrStorageAllocationFailures.2 = Counter32: 0
HOST-RESOURCES-MIB::hrStorageAllocationFailures.3 = Counter32: 0
HOST-RESOURCES-MIB::hrStorageAllocationFailures.4 = Counter32: 0
HOST-RESOURCES-MIB::hrStorageAllocationFailures.5 = Counter32: 0
HOST-RESOURCES-MIB::hrStorageAllocationFailures.6 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceIndex.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrDeviceIndex.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrDeviceIndex.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrDeviceIndex.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrDeviceIndex.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrDeviceIndex.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrDeviceIndex.7 = INTEGER: 7
HOST-RESOURCES-MIB::hrDeviceIndex.8 = INTEGER: 8
HOST-RESOURCES-MIB::hrDeviceIndex.10 = INTEGER: 10
HOST-RESOURCES-MIB::hrDeviceIndex.11 = INTEGER: 11
HOST-RESOURCES-MIB::hrDeviceIndex.12 = INTEGER: 12
HOST-RESOURCES-MIB::hrDeviceType.1 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.2 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.3 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.4 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.5 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.6 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.7 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.8 = OID: HOST-RESOURCES-TYPES::hrDeviceProcessor
HOST-RESOURCES-MIB::hrDeviceType.10 = OID: HOST-RESOURCES-TYPES::hrDeviceNetwork
HOST-RESOURCES-MIB::hrDeviceType.11 = OID: HOST-RESOURCES-TYPES::hrDeviceDiskStorage
HOST-RESOURCES-MIB::hrDeviceType.12 = OID: HOST-RESOURCES-TYPES::hrDeviceDiskStorage
HOST-RESOURCES-MIB::hrDeviceDescr.1 = STRING: CPU Package/ID: 0/0 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.2 = STRING: CPU Package/ID: 0/1 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.3 = STRING: CPU Package/ID: 0/2 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.4 = STRING: CPU Package/ID: 0/3 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.5 = STRING: CPU Package/ID: 0/4 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.6 = STRING: CPU Package/ID: 0/5 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.7 = STRING: CPU Package/ID: 0/6 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.8 = STRING: CPU Package/ID: 0/7 Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz
HOST-RESOURCES-MIB::hrDeviceDescr.10 = STRING: network interface vmnic0, driver r8168, 0000:002:00.0, Realtek 8168 Gigabit Ethernet, , Realtek
HOST-RESOURCES-MIB::hrDeviceDescr.11 = STRING: LUN ATA      WDC WD5000AAKS-7 01.0 t10.ATA_____WDC_WD5000AAKS2D75A7B2________________________WD2DWCASY5786959
HOST-RESOURCES-MIB::hrDeviceDescr.12 = STRING: LUN ATA      CFD CSSD-SM128WJ 1002 t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002
HOST-RESOURCES-MIB::hrDeviceID.1 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.2 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.3 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.4 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.5 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.6 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.7 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.8 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.10 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.11 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceID.12 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrDeviceStatus.1 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.2 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.3 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.4 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.5 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.6 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.7 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.8 = INTEGER: unknown(1)
HOST-RESOURCES-MIB::hrDeviceStatus.10 = INTEGER: running(2)
HOST-RESOURCES-MIB::hrDeviceStatus.11 = INTEGER: running(2)
HOST-RESOURCES-MIB::hrDeviceStatus.12 = INTEGER: running(2)
HOST-RESOURCES-MIB::hrDeviceErrors.1 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.2 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.3 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.4 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.5 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.6 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.7 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.8 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.10 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.11 = Counter32: 0
HOST-RESOURCES-MIB::hrDeviceErrors.12 = Counter32: 0
HOST-RESOURCES-MIB::hrProcessorFrwID.1 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.2 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.3 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.4 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.5 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.6 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.7 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorFrwID.8 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrProcessorLoad.1 = INTEGER: 2
HOST-RESOURCES-MIB::hrProcessorLoad.2 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.3 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.4 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.5 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.6 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.7 = INTEGER: 1
HOST-RESOURCES-MIB::hrProcessorLoad.8 = INTEGER: 1
HOST-RESOURCES-MIB::hrNetworkIfIndex.10 = INTEGER: 1
HOST-RESOURCES-MIB::hrDiskStorageAccess.11 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrDiskStorageAccess.12 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrDiskStorageMedia.11 = INTEGER: hardDisk(3)
HOST-RESOURCES-MIB::hrDiskStorageMedia.12 = INTEGER: hardDisk(3)
HOST-RESOURCES-MIB::hrDiskStorageRemoveble.11 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrDiskStorageRemoveble.12 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrDiskStorageCapacity.11 = INTEGER: 488386584 KBytes
HOST-RESOURCES-MIB::hrDiskStorageCapacity.12 = INTEGER: 125034840 KBytes
HOST-RESOURCES-MIB::hrPartitionIndex.11.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrPartitionIndex.11.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrPartitionIndex.12.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrPartitionIndex.12.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrPartitionIndex.12.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrPartitionIndex.12.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrPartitionIndex.12.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrPartitionIndex.12.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrPartitionIndex.12.7 = INTEGER: 7
HOST-RESOURCES-MIB::hrPartitionIndex.12.8 = INTEGER: 8
HOST-RESOURCES-MIB::hrPartitionLabel.11.1 = STRING: "t10.ATA_____WDC_WD5000AAKS2D75A7B2________________________WD2DWCASY5786959:0"
HOST-RESOURCES-MIB::hrPartitionLabel.11.2 = STRING: "t10.ATA_____WDC_WD5000AAKS2D75A7B2________________________WD2DWCASY5786959:1"
HOST-RESOURCES-MIB::hrPartitionLabel.12.1 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:0"
HOST-RESOURCES-MIB::hrPartitionLabel.12.2 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:1"
HOST-RESOURCES-MIB::hrPartitionLabel.12.3 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:2"
HOST-RESOURCES-MIB::hrPartitionLabel.12.4 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:3"
HOST-RESOURCES-MIB::hrPartitionLabel.12.5 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:5"
HOST-RESOURCES-MIB::hrPartitionLabel.12.6 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:6"
HOST-RESOURCES-MIB::hrPartitionLabel.12.7 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:7"
HOST-RESOURCES-MIB::hrPartitionLabel.12.8 = STRING: "t10.ATA_____CFD_CSSD2DSM128WJ3_______________________04025242011020100002:8"
HOST-RESOURCES-MIB::hrPartitionID.11.1 = STRING: "0"
HOST-RESOURCES-MIB::hrPartitionID.11.2 = STRING: "1"
HOST-RESOURCES-MIB::hrPartitionID.12.1 = STRING: "0"
HOST-RESOURCES-MIB::hrPartitionID.12.2 = STRING: "1"
HOST-RESOURCES-MIB::hrPartitionID.12.3 = STRING: "2"
HOST-RESOURCES-MIB::hrPartitionID.12.4 = STRING: "3"
HOST-RESOURCES-MIB::hrPartitionID.12.5 = STRING: "5"
HOST-RESOURCES-MIB::hrPartitionID.12.6 = STRING: "6"
HOST-RESOURCES-MIB::hrPartitionID.12.7 = STRING: "7"
HOST-RESOURCES-MIB::hrPartitionID.12.8 = STRING: "8"
HOST-RESOURCES-MIB::hrPartitionSize.11.1 = INTEGER: 488386584 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.11.2 = INTEGER: 488383008 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.1 = INTEGER: 125034840 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.2 = INTEGER: 4064 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.3 = INTEGER: 4193280 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.4 = INTEGER: 119919943 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.5 = INTEGER: 255984 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.6 = INTEGER: 255984 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.7 = INTEGER: 112624 KBytes
HOST-RESOURCES-MIB::hrPartitionSize.12.8 = INTEGER: 292848 KBytes
HOST-RESOURCES-MIB::hrPartitionFSIndex.11.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrPartitionFSIndex.11.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.7 = INTEGER: 7
HOST-RESOURCES-MIB::hrPartitionFSIndex.12.8 = INTEGER: 8
HOST-RESOURCES-MIB::hrFSIndex.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrFSIndex.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrFSIndex.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrFSIndex.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrFSIndex.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrFSIndex.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrFSMountPoint.1 = STRING: "/vmfs/volumes/4f14069d-e270c79e-a816-50e549449f2c"
HOST-RESOURCES-MIB::hrFSMountPoint.2 = STRING: "/vmfs/volumes/4f02074e-7a4bdd3e-3cff-50e549449f2c"
HOST-RESOURCES-MIB::hrFSMountPoint.3 = STRING: "/vmfs/volumes/4f52cebb-110a01fa-9d24-50e549449f2c"
HOST-RESOURCES-MIB::hrFSMountPoint.4 = STRING: "/vmfs/volumes/d4fd7172-0c87cf89-9bfd-f43d2230a99d"
HOST-RESOURCES-MIB::hrFSMountPoint.5 = STRING: "/vmfs/volumes/a3b3107c-1e04eddb-4569-107ff98f985c"
HOST-RESOURCES-MIB::hrFSMountPoint.6 = STRING: "/vmfs/volumes/4f52ceb4-b12cef1c-ff29-50e549449f2c"
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.1 = ""
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.2 = ""
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.3 = ""
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.4 = ""
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.5 = ""
HOST-RESOURCES-MIB::hrFSRemoteMountPoint.6 = ""
HOST-RESOURCES-MIB::hrFSType.1 = OID: HOST-RESOURCES-TYPES::hrFSOther
HOST-RESOURCES-MIB::hrFSType.2 = OID: HOST-RESOURCES-TYPES::hrFSOther
HOST-RESOURCES-MIB::hrFSType.3 = OID: HOST-RESOURCES-TYPES::hrFSFAT32
HOST-RESOURCES-MIB::hrFSType.4 = OID: HOST-RESOURCES-TYPES::hrFSFAT32
HOST-RESOURCES-MIB::hrFSType.5 = OID: HOST-RESOURCES-TYPES::hrFSFAT32
HOST-RESOURCES-MIB::hrFSType.6 = OID: HOST-RESOURCES-TYPES::hrFSFAT32
HOST-RESOURCES-MIB::hrFSAccess.1 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSAccess.2 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSAccess.3 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSAccess.4 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSAccess.5 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSAccess.6 = INTEGER: readWrite(1)
HOST-RESOURCES-MIB::hrFSBootable.1 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrFSBootable.2 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrFSBootable.3 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrFSBootable.4 = INTEGER: true(1)
HOST-RESOURCES-MIB::hrFSBootable.5 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrFSBootable.6 = INTEGER: false(2)
HOST-RESOURCES-MIB::hrFSStorageIndex.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrFSStorageIndex.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrFSStorageIndex.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrFSStorageIndex.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrFSStorageIndex.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrFSStorageIndex.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.1 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.2 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.3 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.4 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.5 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastFullBackupDate.6 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.1 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.2 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.3 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.4 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.5 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrFSLastPartialBackupDate.6 = STRING: 0-0-0,0:0:0.0
HOST-RESOURCES-MIB::hrSWRunIndex.2179 = INTEGER: 2179
HOST-RESOURCES-MIB::hrSWRunIndex.2641 = INTEGER: 2641
HOST-RESOURCES-MIB::hrSWRunIndex.2642 = INTEGER: 2642
HOST-RESOURCES-MIB::hrSWRunIndex.2662 = INTEGER: 2662
HOST-RESOURCES-MIB::hrSWRunIndex.2676 = INTEGER: 2676
HOST-RESOURCES-MIB::hrSWRunIndex.2701 = INTEGER: 2701
HOST-RESOURCES-MIB::hrSWRunIndex.2702 = INTEGER: 2702
HOST-RESOURCES-MIB::hrSWRunIndex.3356 = INTEGER: 3356
HOST-RESOURCES-MIB::hrSWRunIndex.3357 = INTEGER: 3357
HOST-RESOURCES-MIB::hrSWRunIndex.5108 = INTEGER: 5108
HOST-RESOURCES-MIB::hrSWRunIndex.6463 = INTEGER: 6463
HOST-RESOURCES-MIB::hrSWRunIndex.7415 = INTEGER: 7415
HOST-RESOURCES-MIB::hrSWRunIndex.7486 = INTEGER: 7486
HOST-RESOURCES-MIB::hrSWRunIndex.7493 = INTEGER: 7493
HOST-RESOURCES-MIB::hrSWRunIndex.7616 = INTEGER: 7616
HOST-RESOURCES-MIB::hrSWRunIndex.8072 = INTEGER: 8072
HOST-RESOURCES-MIB::hrSWRunIndex.8389 = INTEGER: 8389
HOST-RESOURCES-MIB::hrSWRunIndex.58505 = INTEGER: 58505
HOST-RESOURCES-MIB::hrSWRunIndex.66426 = INTEGER: 66426
HOST-RESOURCES-MIB::hrSWRunIndex.66433 = INTEGER: 66433
HOST-RESOURCES-MIB::hrSWRunIndex.66446 = INTEGER: 66446
HOST-RESOURCES-MIB::hrSWRunIndex.66453 = INTEGER: 66453
HOST-RESOURCES-MIB::hrSWRunIndex.66472 = INTEGER: 66472
HOST-RESOURCES-MIB::hrSWRunIndex.66479 = INTEGER: 66479
HOST-RESOURCES-MIB::hrSWRunIndex.66555 = INTEGER: 66555
HOST-RESOURCES-MIB::hrSWRunIndex.66559 = INTEGER: 66559
HOST-RESOURCES-MIB::hrSWRunIndex.66640 = INTEGER: 66640
HOST-RESOURCES-MIB::hrSWRunIndex.66660 = INTEGER: 66660
HOST-RESOURCES-MIB::hrSWRunIndex.66667 = INTEGER: 66667
HOST-RESOURCES-MIB::hrSWRunIndex.66685 = INTEGER: 66685
HOST-RESOURCES-MIB::hrSWRunIndex.66692 = INTEGER: 66692
HOST-RESOURCES-MIB::hrSWRunIndex.66710 = INTEGER: 66710
HOST-RESOURCES-MIB::hrSWRunIndex.66717 = INTEGER: 66717
HOST-RESOURCES-MIB::hrSWRunIndex.66750 = INTEGER: 66750
HOST-RESOURCES-MIB::hrSWRunIndex.66757 = INTEGER: 66757
HOST-RESOURCES-MIB::hrSWRunIndex.66762 = INTEGER: 66762
HOST-RESOURCES-MIB::hrSWRunIndex.66800 = INTEGER: 66800
HOST-RESOURCES-MIB::hrSWRunIndex.66841 = INTEGER: 66841
HOST-RESOURCES-MIB::hrSWRunIndex.67001 = INTEGER: 67001
HOST-RESOURCES-MIB::hrSWRunIndex.67018 = INTEGER: 67018
HOST-RESOURCES-MIB::hrSWRunIndex.67019 = INTEGER: 67019
HOST-RESOURCES-MIB::hrSWRunIndex.67020 = INTEGER: 67020
HOST-RESOURCES-MIB::hrSWRunIndex.67030 = INTEGER: 67030
HOST-RESOURCES-MIB::hrSWRunIndex.67092 = INTEGER: 67092
HOST-RESOURCES-MIB::hrSWRunIndex.67098 = INTEGER: 67098
HOST-RESOURCES-MIB::hrSWRunIndex.67104 = INTEGER: 67104
HOST-RESOURCES-MIB::hrSWRunIndex.67283 = INTEGER: 67283
HOST-RESOURCES-MIB::hrSWRunIndex.423040 = INTEGER: 423040
HOST-RESOURCES-MIB::hrSWRunIndex.906251 = INTEGER: 906251
HOST-RESOURCES-MIB::hrSWRunName.2179 = STRING: "init"
HOST-RESOURCES-MIB::hrSWRunName.2641 = STRING: "python"
HOST-RESOURCES-MIB::hrSWRunName.2642 = STRING: "python"
HOST-RESOURCES-MIB::hrSWRunName.2662 = STRING: "vmkeventd"
HOST-RESOURCES-MIB::hrSWRunName.2676 = STRING: "vmkdevmgr"
HOST-RESOURCES-MIB::hrSWRunName.2701 = STRING: "busybox"
HOST-RESOURCES-MIB::hrSWRunName.2702 = STRING: "busybox"
HOST-RESOURCES-MIB::hrSWRunName.3356 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.3357 = STRING: "dcui"
HOST-RESOURCES-MIB::hrSWRunName.5108 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.6463 = STRING: "vmx"
HOST-RESOURCES-MIB::hrSWRunName.7415 = STRING: "vmware-usbarbitrator"
HOST-RESOURCES-MIB::hrSWRunName.7486 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.7493 = STRING: "openwsmand"
HOST-RESOURCES-MIB::hrSWRunName.7616 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.8072 = STRING: "vmx"
HOST-RESOURCES-MIB::hrSWRunName.8389 = STRING: "vmx"
HOST-RESOURCES-MIB::hrSWRunName.58505 = STRING: "vmx"
HOST-RESOURCES-MIB::hrSWRunName.66426 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66433 = STRING: "storageRM"
HOST-RESOURCES-MIB::hrSWRunName.66446 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66453 = STRING: "net-lbt"
HOST-RESOURCES-MIB::hrSWRunName.66472 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66479 = STRING: "vprobed"
HOST-RESOURCES-MIB::hrSWRunName.66555 = STRING: "hostd"
HOST-RESOURCES-MIB::hrSWRunName.66559 = STRING: "nssquery"
HOST-RESOURCES-MIB::hrSWRunName.66640 = STRING: "slpd"
HOST-RESOURCES-MIB::hrSWRunName.66660 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66667 = STRING: "dcbd"
HOST-RESOURCES-MIB::hrSWRunName.66685 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66692 = STRING: "net-cdp"
HOST-RESOURCES-MIB::hrSWRunName.66710 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66717 = STRING: "vobd"
HOST-RESOURCES-MIB::hrSWRunName.66750 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66757 = STRING: "vpxa"
HOST-RESOURCES-MIB::hrSWRunName.66762 = STRING: "nssquery"
HOST-RESOURCES-MIB::hrSWRunName.66800 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.66841 = STRING: "sh"
HOST-RESOURCES-MIB::hrSWRunName.67001 = STRING: "cimslp"
HOST-RESOURCES-MIB::hrSWRunName.67018 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67019 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67020 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67030 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67092 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67098 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67104 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.67283 = STRING: "sfcbd"
HOST-RESOURCES-MIB::hrSWRunName.423040 = STRING: "vmx"
HOST-RESOURCES-MIB::hrSWRunName.906251 = STRING: "sleep"
HOST-RESOURCES-MIB::hrSWRunID.2179 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2641 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2642 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2662 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2676 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2701 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.2702 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.3356 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.3357 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.5108 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.6463 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.7415 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.7486 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.7493 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.7616 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.8072 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.8389 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.58505 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66426 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66433 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66446 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66453 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66472 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66479 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66555 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66559 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66640 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66660 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66667 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66685 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66692 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66710 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66717 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66750 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66757 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66762 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66800 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.66841 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67001 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67018 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67019 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67020 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67030 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67092 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67098 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67104 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.67283 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.423040 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunID.906251 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWRunPath.2179 = STRING: "/sbin/init"
HOST-RESOURCES-MIB::hrSWRunPath.2641 = STRING: "/bin/python"
HOST-RESOURCES-MIB::hrSWRunPath.2642 = STRING: "/bin/python"
HOST-RESOURCES-MIB::hrSWRunPath.2662 = STRING: "/usr/lib/vmware/bin/vmkeventd"
HOST-RESOURCES-MIB::hrSWRunPath.2676 = STRING: "/usr/sbin/vmkdevmgr"
HOST-RESOURCES-MIB::hrSWRunPath.2701 = STRING: "/bin/busybox"
HOST-RESOURCES-MIB::hrSWRunPath.2702 = STRING: "/bin/busybox"
HOST-RESOURCES-MIB::hrSWRunPath.3356 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.3357 = STRING: "/sbin/dcui"
HOST-RESOURCES-MIB::hrSWRunPath.5108 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.6463 = STRING: "/bin/vmx"
HOST-RESOURCES-MIB::hrSWRunPath.7415 = STRING: "/usr/lib/vmware/bin/vmware-usbarbitrator"
HOST-RESOURCES-MIB::hrSWRunPath.7486 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.7493 = STRING: "/sbin/openwsmand"
HOST-RESOURCES-MIB::hrSWRunPath.7616 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.8072 = STRING: "/bin/vmx"
HOST-RESOURCES-MIB::hrSWRunPath.8389 = STRING: "/bin/vmx"
HOST-RESOURCES-MIB::hrSWRunPath.58505 = STRING: "/bin/vmx"
HOST-RESOURCES-MIB::hrSWRunPath.66426 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66433 = STRING: "/sbin/storageRM"
HOST-RESOURCES-MIB::hrSWRunPath.66446 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66453 = STRING: "/sbin/net-lbt"
HOST-RESOURCES-MIB::hrSWRunPath.66472 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66479 = STRING: "/sbin/vprobed"
HOST-RESOURCES-MIB::hrSWRunPath.66555 = STRING: "hostd"
HOST-RESOURCES-MIB::hrSWRunPath.66559 = STRING: "/usr/libexec/hostd/nssquery"
HOST-RESOURCES-MIB::hrSWRunPath.66640 = STRING: "/sbin/slpd"
HOST-RESOURCES-MIB::hrSWRunPath.66660 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66667 = STRING: "/usr/sbin/dcbd"
HOST-RESOURCES-MIB::hrSWRunPath.66685 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66692 = STRING: "/usr/sbin/net-cdp"
HOST-RESOURCES-MIB::hrSWRunPath.66710 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66717 = STRING: "/usr/lib/vmware/vob/bin/vobd"
HOST-RESOURCES-MIB::hrSWRunPath.66750 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66757 = STRING: "/usr/lib/vmware/vpxa/bin/vpxa"
HOST-RESOURCES-MIB::hrSWRunPath.66762 = STRING: "/usr/libexec/hostd/nssquery"
HOST-RESOURCES-MIB::hrSWRunPath.66800 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.66841 = STRING: "/bin/sh"
HOST-RESOURCES-MIB::hrSWRunPath.67001 = STRING: "/bin/cimslp"
HOST-RESOURCES-MIB::hrSWRunPath.67018 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67019 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67020 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67030 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67092 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67098 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67104 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.67283 = STRING: "/sbin/sfcbd"
HOST-RESOURCES-MIB::hrSWRunPath.423040 = STRING: "/bin/vmx"
HOST-RESOURCES-MIB::hrSWRunPath.906251 = STRING: "sleep"
HOST-RESOURCES-MIB::hrSWRunParameters.2179 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.2641 = STRING: "-OO /usr/lib/vmware/vmsyslog/bin/vmsyslogd -i"
HOST-RESOURCES-MIB::hrSWRunParameters.2642 = STRING: "-OO /usr/lib/vmware/vmsyslog/bin/vmsyslogd -i"
HOST-RESOURCES-MIB::hrSWRunParameters.2662 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.2676 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.2701 = STRING: "inetd /var/run/inetd.conf"
HOST-RESOURCES-MIB::hrSWRunParameters.2702 = STRING: "crond"
HOST-RESOURCES-MIB::hrSWRunParameters.3356 = STRING: "/sbin/techsupport.sh"
HOST-RESOURCES-MIB::hrSWRunParameters.3357 = STRING: "2"
HOST-RESOURCES-MIB::hrSWRunParameters.5108 = STRING: "/sbin/watchdog.sh -s hostd hostd ++min=0,swap,group=hostd /etc/vmware/hostd/config.xml"
HOST-RESOURCES-MIB::hrSWRunParameters.6463 = STRING: "-ssched.group=host/user -# name=VMware ESX;version=5.0.0;buildnumber=469512;licensename=VMware ESX Server;licenseversion=5.0 bu"
HOST-RESOURCES-MIB::hrSWRunParameters.7415 = STRING: "-t"
HOST-RESOURCES-MIB::hrSWRunParameters.7486 = STRING: "/sbin/watchdog.sh -s openwsmand -u 60 -q 5 -t 10 /sbin/openwsmand ++min=0,swap,group=wsman,securitydom=4 --syslog=3 --foregroun"
HOST-RESOURCES-MIB::hrSWRunParameters.7493 = STRING: "--syslog=3 --foreground-process"
HOST-RESOURCES-MIB::hrSWRunParameters.7616 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.8072 = STRING: "-ssched.group=host/user -# name=VMware ESX;version=5.0.0;buildnumber=469512;licensename=VMware ESX Server;licenseversion=5.0 bu"
HOST-RESOURCES-MIB::hrSWRunParameters.8389 = STRING: "-ssched.group=host/user -# name=VMware ESX;version=5.0.0;buildnumber=469512;licensename=VMware ESX Server;licenseversion=5.0 bu"
HOST-RESOURCES-MIB::hrSWRunParameters.58505 = STRING: "-ssched.group=host/user -# name=VMware ESX;version=5.0.0;buildnumber=469512;licensename=VMware ESX Server;licenseversion=5.0 bu"
HOST-RESOURCES-MIB::hrSWRunParameters.66426 = STRING: "/sbin/watchdog.sh -s storageRM /sbin/storageRM ++group=sioc"
HOST-RESOURCES-MIB::hrSWRunParameters.66433 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66446 = STRING: "/sbin/watchdog.sh -s net-lbt -u 1000 -q 100 -t 100 /sbin/net-lbt ++min=0,swap,group=lbt"
HOST-RESOURCES-MIB::hrSWRunParameters.66453 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66472 = STRING: "/sbin/watchdog.sh -s vprobed /sbin/vprobed ++group=vprobed"
HOST-RESOURCES-MIB::hrSWRunParameters.66479 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66555 = STRING: "/etc/vmware/hostd/config.xml"
HOST-RESOURCES-MIB::hrSWRunParameters.66559 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66640 = STRING: "-l /dev/null"
HOST-RESOURCES-MIB::hrSWRunParameters.66660 = STRING: "/sbin/watchdog.sh -s dcbd -t 5 /usr/sbin/dcbd ++group=net-daemons"
HOST-RESOURCES-MIB::hrSWRunParameters.66667 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66685 = STRING: "/sbin/watchdog.sh -s cdp /usr/sbin/net-cdp ++group=net-daemons"
HOST-RESOURCES-MIB::hrSWRunParameters.66692 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66710 = STRING: "/sbin/watchdog.sh -s vobd /usr/lib/vmware/vob/bin/vobd ++min=0,max=100,group=uwdaemons"
HOST-RESOURCES-MIB::hrSWRunParameters.66717 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66750 = STRING: "/sbin/watchdog.sh -s vpxa /usr/lib/vmware/vpxa/bin/vpxa ++min=0,swap,group=vpxa -D /etc/vmware/vpxa"
HOST-RESOURCES-MIB::hrSWRunParameters.66757 = STRING: "-D /etc/vmware/vpxa"
HOST-RESOURCES-MIB::hrSWRunParameters.66762 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.66800 = STRING: "/sbin/watchdog.sh -s usbarbitrator -t 5 /usr/lib/vmware/bin/vmware-usbarbitrator ++min=0,max=25,group=uwdaemons -t"
HOST-RESOURCES-MIB::hrSWRunParameters.66841 = STRING: "/etc/init.d/sfcbd-watchdog start"
HOST-RESOURCES-MIB::hrSWRunParameters.67001 = ""
HOST-RESOURCES-MIB::hrSWRunParameters.67018 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67019 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67020 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67030 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67092 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67098 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67104 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.67283 = STRING: "-d -l 3"
HOST-RESOURCES-MIB::hrSWRunParameters.423040 = STRING: "-ssched.group=host/user -# name=VMware ESX;version=5.0.0;buildnumber=469512;licensename=VMware ESX Server;licenseversion=5.0 bu"
HOST-RESOURCES-MIB::hrSWRunParameters.906251 = STRING: "60"
HOST-RESOURCES-MIB::hrSWRunType.2179 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2641 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2642 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2662 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2676 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2701 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.2702 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.3356 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.3357 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.5108 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.6463 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.7415 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.7486 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.7493 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.7616 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.8072 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.8389 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.58505 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66426 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66433 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66446 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66453 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66472 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66479 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66555 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66559 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66640 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66660 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66667 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66685 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66692 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66710 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66717 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66750 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66757 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66762 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66800 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.66841 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67001 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67018 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67019 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67020 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67030 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67092 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67098 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67104 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.67283 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.423040 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunType.906251 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWRunStatus.2179 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2641 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2642 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2662 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2676 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2701 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.2702 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.3356 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.3357 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.5108 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.6463 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.7415 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.7486 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.7493 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.7616 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.8072 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.8389 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.58505 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66426 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66433 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66446 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66453 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66472 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66479 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66555 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66559 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66640 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66660 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66667 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66685 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66692 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66710 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66717 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66750 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66757 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66762 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66800 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.66841 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67001 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67018 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67019 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67020 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67030 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67092 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67098 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67104 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.67283 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.423040 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunStatus.906251 = INTEGER: notRunnable(3)
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2179 = INTEGER: 1
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2641 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2642 = INTEGER: 1112
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2662 = INTEGER: 1
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2676 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2701 = INTEGER: 2
HOST-RESOURCES-MIB::hrSWRunPerfCPU.2702 = INTEGER: 104
HOST-RESOURCES-MIB::hrSWRunPerfCPU.3356 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.3357 = INTEGER: 16
HOST-RESOURCES-MIB::hrSWRunPerfCPU.5108 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.6463 = INTEGER: 1510819
HOST-RESOURCES-MIB::hrSWRunPerfCPU.7415 = INTEGER: 4061
HOST-RESOURCES-MIB::hrSWRunPerfCPU.7486 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.7493 = INTEGER: 1424
HOST-RESOURCES-MIB::hrSWRunPerfCPU.7616 = INTEGER: 1752
HOST-RESOURCES-MIB::hrSWRunPerfCPU.8072 = INTEGER: 387066
HOST-RESOURCES-MIB::hrSWRunPerfCPU.8389 = INTEGER: 599881
HOST-RESOURCES-MIB::hrSWRunPerfCPU.58505 = INTEGER: 2015050
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66426 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66433 = INTEGER: 82
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66446 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66453 = INTEGER: 469
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66472 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66479 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66555 = INTEGER: 26348
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66559 = INTEGER: 121
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66640 = INTEGER: 125
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66660 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66667 = INTEGER: 1683
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66685 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66692 = INTEGER: 10
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66710 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66717 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66750 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66757 = INTEGER: 15718
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66762 = INTEGER: 1
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66800 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfCPU.66841 = INTEGER: 6633
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67001 = INTEGER: 125
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67018 = INTEGER: 34
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67019 = INTEGER: 1692
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67020 = INTEGER: 3591
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67030 = INTEGER: 10
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67092 = INTEGER: 59
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67098 = INTEGER: 58
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67104 = INTEGER: 54
HOST-RESOURCES-MIB::hrSWRunPerfCPU.67283 = INTEGER: 64
HOST-RESOURCES-MIB::hrSWRunPerfCPU.423040 = INTEGER: 213969
HOST-RESOURCES-MIB::hrSWRunPerfCPU.906251 = INTEGER: 0
HOST-RESOURCES-MIB::hrSWRunPerfMem.2179 = INTEGER: 2460 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2641 = INTEGER: 4736 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2642 = INTEGER: 6640 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2662 = INTEGER: 3080 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2676 = INTEGER: 2052 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2701 = INTEGER: 940 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.2702 = INTEGER: 940 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.3356 = INTEGER: 2588 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.3357 = INTEGER: 3564 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.5108 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.6463 = INTEGER: 2097152 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.7415 = INTEGER: 3124 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.7486 = INTEGER: 672 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.7493 = INTEGER: 956 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.7616 = INTEGER: 1076 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.8072 = INTEGER: 2097152 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.8389 = INTEGER: 2097152 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.58505 = INTEGER: 4194304 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66426 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66433 = INTEGER: 2800 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66446 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66453 = INTEGER: 1920 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66472 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66479 = INTEGER: 2624 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66555 = INTEGER: 60056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66559 = INTEGER: 1028 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66640 = INTEGER: 1272 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66660 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66667 = INTEGER: 1552 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66685 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66692 = INTEGER: 1088 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66710 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66717 = INTEGER: 9156 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66750 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66757 = INTEGER: 23528 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66762 = INTEGER: 1028 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66800 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.66841 = INTEGER: 1056 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67001 = INTEGER: 1672 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67018 = INTEGER: 1000 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67019 = INTEGER: 1000 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67020 = INTEGER: 3788 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67030 = INTEGER: 2316 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67092 = INTEGER: 15456 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67098 = INTEGER: 2832 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67104 = INTEGER: 7512 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.67283 = INTEGER: 3832 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.423040 = INTEGER: 2097152 KBytes
HOST-RESOURCES-MIB::hrSWRunPerfMem.906251 = INTEGER: 796 KBytes
HOST-RESOURCES-MIB::hrSWInstalledLastChange.0 = Timeticks: (127915467) 14 days, 19:19:14.67
HOST-RESOURCES-MIB::hrSWInstalledLastUpdateTime.0 = Timeticks: (127915467) 14 days, 19:19:14.67
HOST-RESOURCES-MIB::hrSWInstalledIndex.1 = INTEGER: 1
HOST-RESOURCES-MIB::hrSWInstalledIndex.2 = INTEGER: 2
HOST-RESOURCES-MIB::hrSWInstalledIndex.3 = INTEGER: 3
HOST-RESOURCES-MIB::hrSWInstalledIndex.4 = INTEGER: 4
HOST-RESOURCES-MIB::hrSWInstalledIndex.5 = INTEGER: 5
HOST-RESOURCES-MIB::hrSWInstalledIndex.6 = INTEGER: 6
HOST-RESOURCES-MIB::hrSWInstalledIndex.7 = INTEGER: 7
HOST-RESOURCES-MIB::hrSWInstalledIndex.8 = INTEGER: 8
HOST-RESOURCES-MIB::hrSWInstalledIndex.9 = INTEGER: 9
HOST-RESOURCES-MIB::hrSWInstalledIndex.10 = INTEGER: 10
HOST-RESOURCES-MIB::hrSWInstalledIndex.11 = INTEGER: 11
HOST-RESOURCES-MIB::hrSWInstalledIndex.12 = INTEGER: 12
HOST-RESOURCES-MIB::hrSWInstalledIndex.13 = INTEGER: 13
HOST-RESOURCES-MIB::hrSWInstalledIndex.14 = INTEGER: 14
HOST-RESOURCES-MIB::hrSWInstalledIndex.15 = INTEGER: 15
HOST-RESOURCES-MIB::hrSWInstalledIndex.16 = INTEGER: 16
HOST-RESOURCES-MIB::hrSWInstalledIndex.17 = INTEGER: 17
HOST-RESOURCES-MIB::hrSWInstalledIndex.18 = INTEGER: 18
HOST-RESOURCES-MIB::hrSWInstalledIndex.19 = INTEGER: 19
HOST-RESOURCES-MIB::hrSWInstalledIndex.20 = INTEGER: 20
HOST-RESOURCES-MIB::hrSWInstalledIndex.21 = INTEGER: 21
HOST-RESOURCES-MIB::hrSWInstalledIndex.22 = INTEGER: 22
HOST-RESOURCES-MIB::hrSWInstalledIndex.23 = INTEGER: 23
HOST-RESOURCES-MIB::hrSWInstalledIndex.24 = INTEGER: 24
HOST-RESOURCES-MIB::hrSWInstalledIndex.25 = INTEGER: 25
HOST-RESOURCES-MIB::hrSWInstalledIndex.26 = INTEGER: 26
HOST-RESOURCES-MIB::hrSWInstalledIndex.27 = INTEGER: 27
HOST-RESOURCES-MIB::hrSWInstalledIndex.28 = INTEGER: 28
HOST-RESOURCES-MIB::hrSWInstalledIndex.29 = INTEGER: 29
HOST-RESOURCES-MIB::hrSWInstalledIndex.30 = INTEGER: 30
HOST-RESOURCES-MIB::hrSWInstalledIndex.31 = INTEGER: 31
HOST-RESOURCES-MIB::hrSWInstalledIndex.32 = INTEGER: 32
HOST-RESOURCES-MIB::hrSWInstalledIndex.33 = INTEGER: 33
HOST-RESOURCES-MIB::hrSWInstalledIndex.34 = INTEGER: 34
HOST-RESOURCES-MIB::hrSWInstalledIndex.35 = INTEGER: 35
HOST-RESOURCES-MIB::hrSWInstalledIndex.36 = INTEGER: 36
HOST-RESOURCES-MIB::hrSWInstalledIndex.37 = INTEGER: 37
HOST-RESOURCES-MIB::hrSWInstalledIndex.38 = INTEGER: 38
HOST-RESOURCES-MIB::hrSWInstalledIndex.39 = INTEGER: 39
HOST-RESOURCES-MIB::hrSWInstalledIndex.40 = INTEGER: 40
HOST-RESOURCES-MIB::hrSWInstalledIndex.41 = INTEGER: 41
HOST-RESOURCES-MIB::hrSWInstalledIndex.42 = INTEGER: 42
HOST-RESOURCES-MIB::hrSWInstalledIndex.43 = INTEGER: 43
HOST-RESOURCES-MIB::hrSWInstalledIndex.44 = INTEGER: 44
HOST-RESOURCES-MIB::hrSWInstalledIndex.45 = INTEGER: 45
HOST-RESOURCES-MIB::hrSWInstalledIndex.46 = INTEGER: 46
HOST-RESOURCES-MIB::hrSWInstalledIndex.47 = INTEGER: 47
HOST-RESOURCES-MIB::hrSWInstalledIndex.48 = INTEGER: 48
HOST-RESOURCES-MIB::hrSWInstalledIndex.49 = INTEGER: 49
HOST-RESOURCES-MIB::hrSWInstalledIndex.50 = INTEGER: 50
HOST-RESOURCES-MIB::hrSWInstalledIndex.51 = INTEGER: 51
HOST-RESOURCES-MIB::hrSWInstalledIndex.52 = INTEGER: 52
HOST-RESOURCES-MIB::hrSWInstalledIndex.53 = INTEGER: 53
HOST-RESOURCES-MIB::hrSWInstalledIndex.54 = INTEGER: 54
HOST-RESOURCES-MIB::hrSWInstalledIndex.55 = INTEGER: 55
HOST-RESOURCES-MIB::hrSWInstalledIndex.56 = INTEGER: 56
HOST-RESOURCES-MIB::hrSWInstalledIndex.57 = INTEGER: 57
HOST-RESOURCES-MIB::hrSWInstalledIndex.58 = INTEGER: 58
HOST-RESOURCES-MIB::hrSWInstalledIndex.59 = INTEGER: 59
HOST-RESOURCES-MIB::hrSWInstalledName.1 = STRING: "VMware,ata-pata-amd,0.3.10-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.2 = STRING: "VMware,ata-pata-atiixp,0.4.6-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.3 = STRING: "VMware,ata-pata-cmd64x,0.2.5-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.4 = STRING: "VMware,ata-pata-hpt3x2n,0.3.4-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.5 = STRING: "VMware,ata-pata-pdc2027x,1.0-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.6 = STRING: "VMware,ata-pata-serverworks,0.4.3-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.7 = STRING: "VMware,ata-pata-sil680,0.4.8-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.8 = STRING: "VMware,ata-pata-via,0.3.3-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.9 = STRING: "VMware,block-cciss,3.6.14-10vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.10 = STRING: "VMware,ehci-ehci-hcd,1.0-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.11 = STRING: "VMware,esx-base,5.0.0-0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.12 = STRING: "VMware,esx-tboot,5.0.0-0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.13 = STRING: "VMware,ima-qla4xxx,2.01.07-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.14 = STRING: "VMware,ipmi-ipmi-devintf,39.1-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.15 = STRING: "VMware,ipmi-ipmi-msghandler,39.1-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.16 = STRING: "VMware,ipmi-ipmi-si-drv,39.1-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.17 = STRING: "VMware,misc-cnic-register,1.1-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.18 = STRING: "VMware,misc-drivers,5.0.0-0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.19 = STRING: "VMware,net-be2net,4.0.88.0-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.20 = STRING: "VMware,net-bnx2,2.0.15g.v50.11-5vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.21 = STRING: "VMware,net-bnx2x,1.61.15.v50.1-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.22 = STRING: "VMware,net-cnic,1.10.2j.v50.7-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.23 = STRING: "VMware,net-e1000,8.0.3.1-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.24 = STRING: "VMware,net-e1000e,1.1.2-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.25 = STRING: "VMware,net-enic,1.4.2.15a-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.26 = STRING: "VMware,net-forcedeth,0.61-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.27 = STRING: "VMware,net-igb,2.1.11.1-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.28 = STRING: "VMware,net-ixgbe,2.0.84.8.2-10vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.29 = STRING: "VMware,net-nx-nic,4.0.557-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.30 = STRING: "VMware,net-r8168,8.013.00-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.31 = STRING: "VMware,net-r8169,6.011.00-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.32 = STRING: "VMware,net-s2io,2.1.4.13427-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.33 = STRING: "VMware,net-sky2,1.20-2vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.34 = STRING: "VMware,net-tg3,3.110h.v50.4-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.35 = STRING: "VMware,ohci-usb-ohci,1.0-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.36 = STRING: "VMware,sata-ahci,3.0-6vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.37 = STRING: "VMware,sata-ata-piix,2.12-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.38 = STRING: "VMware,sata-sata-nv,3.5-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.39 = STRING: "VMware,sata-sata-promise,2.12-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.40 = STRING: "VMware,sata-sata-sil,2.3-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.41 = STRING: "VMware,sata-sata-svw,2.3-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.42 = STRING: "VMware,scsi-aacraid,1.1.5.1-9vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.43 = STRING: "VMware,scsi-adp94xx,1.0.8.12-6vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.44 = STRING: "VMware,scsi-aic79xx,3.1-5vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.45 = STRING: "VMware,scsi-bnx2i,1.9.1d.v50.1-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.46 = STRING: "VMware,scsi-fnic,1.5.0.3-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.47 = STRING: "VMware,scsi-hpsa,5.0.0-17vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.48 = STRING: "VMware,scsi-ips,7.12.05-4vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.49 = STRING: "VMware,scsi-lpfc820,8.2.2.1-18vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.50 = STRING: "VMware,scsi-megaraid-mbox,2.20.5.1-6vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.51 = STRING: "VMware,scsi-megaraid-sas,4.32-1vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.52 = STRING: "VMware,scsi-megaraid2,2.00.4-9vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.53 = STRING: "VMware,scsi-mpt2sas,06.00.00.00-5vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.54 = STRING: "VMware,scsi-mptsas,4.23.01.00-5vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.55 = STRING: "VMware,scsi-mptspi,4.23.01.00-5vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.56 = STRING: "VMware,scsi-qla2xxx,901.k1.1-14vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.57 = STRING: "VMware,scsi-qla4xxx,5.01.03.2-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.58 = STRING: "VMware,uhci-usb-uhci,1.0-3vmw.500.0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledName.59 = STRING: "VMware,tools-light,5.0.0-0.0.469512,"
HOST-RESOURCES-MIB::hrSWInstalledID.1 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.2 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.3 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.4 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.5 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.6 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.7 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.8 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.9 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.10 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.11 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.12 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.13 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.14 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.15 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.16 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.17 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.18 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.19 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.20 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.21 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.22 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.23 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.24 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.25 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.26 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.27 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.28 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.29 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.30 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.31 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.32 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.33 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.34 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.35 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.36 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.37 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.38 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.39 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.40 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.41 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.42 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.43 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.44 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.45 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.46 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.47 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.48 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.49 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.50 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.51 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.52 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.53 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.54 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.55 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.56 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.57 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.58 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledID.59 = OID: SNMPv2-SMI::zeroDotZero
HOST-RESOURCES-MIB::hrSWInstalledType.1 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.2 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.3 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.4 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.5 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.6 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.7 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.8 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.9 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.10 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.11 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.12 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.13 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.14 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.15 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.16 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.17 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.18 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.19 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.20 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.21 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.22 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.23 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.24 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.25 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.26 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.27 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.28 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.29 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.30 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.31 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.32 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.33 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.34 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.35 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.36 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.37 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.38 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.39 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.40 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.41 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.42 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.43 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.44 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.45 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.46 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.47 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.48 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.49 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.50 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.51 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.52 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.53 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.54 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.55 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.56 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.57 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.58 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledType.59 = INTEGER: application(4)
HOST-RESOURCES-MIB::hrSWInstalledDate.1 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.2 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.3 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.4 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.5 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.6 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.7 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.8 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.9 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.10 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.11 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.12 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.13 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.14 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.15 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.16 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.17 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.18 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.19 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.20 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.21 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.22 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.23 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.24 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.25 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.26 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.27 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.28 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.29 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.30 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.31 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.32 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.33 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.34 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.35 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.36 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.37 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.38 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.39 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.40 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.41 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.42 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.43 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.44 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.45 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.46 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.47 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.48 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.49 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.50 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.51 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.52 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.53 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.54 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.55 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.56 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.57 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.58 = STRING: 0-1-1,0:0:0.0
HOST-RESOURCES-MIB::hrSWInstalledDate.59 = STRING: 0-1-1,0:0:0.0
IF-MIB::ifName.1 = STRING: vmnic0
IF-MIB::ifInMulticastPkts.1 = Counter32: 232388
IF-MIB::ifInBroadcastPkts.1 = Counter32: 192431
IF-MIB::ifOutMulticastPkts.1 = Counter32: 1020135
IF-MIB::ifOutBroadcastPkts.1 = Counter32: 2445571
IF-MIB::ifHCInOctets.1 = Counter64: 3527229789
IF-MIB::ifHCInUcastPkts.1 = Counter64: 40699475
IF-MIB::ifHCInMulticastPkts.1 = Counter64: 232388
IF-MIB::ifHCInBroadcastPkts.1 = Counter64: 192431
IF-MIB::ifHCOutOctets.1 = Counter64: 3698549733
IF-MIB::ifHCOutUcastPkts.1 = Counter64: 41756122
IF-MIB::ifHCOutMulticastPkts.1 = Counter64: 1020135
IF-MIB::ifHCOutBroadcastPkts.1 = Counter64: 2445571
IF-MIB::ifLinkUpDownTrapEnable.1 = INTEGER: enabled(1)
IF-MIB::ifHighSpeed.1 = Gauge32: 1000
IF-MIB::ifPromiscuousMode.1 = INTEGER: true(1)
IF-MIB::ifConnectorPresent.1 = INTEGER: true(1)
IF-MIB::ifAlias.1 = STRING: 02:00.0
IF-MIB::ifCounterDiscontinuityTime.1 = Timeticks: (0) 0:00:00.00
IF-MIB::ifTableLastChange.0 = Timeticks: (111876836) 12 days, 22:46:08.36

snmpって奥が深いのね・・・。

NTPサーバ設定

Zabbix構築するにあたり、各サーバのログ等時刻同期が必要だと思ったので早急にNTPサーバ
を構築したときのメモである。

#vi /etc/ntp.conf

driftfile /var/lib/ntp/drift restrict default kod nomodify notrap nopeer noquery restrict -6 default kod nomodify notrap nopeer noquery restrict 127.0.0.1 restrict -6 ::1 restrict 192.168.230.0 mask 255.255.255.0 nomodify notrap server ntp1.jst.mfeed.ad.jp server ntp2.jst.mfeed.ad.jp server ntp3.jst.mfeed.ad.jp includefile /etc/ntp/crypto/pw keys /etc/ntp/keys

ntpdを起動させて、時刻が同期されているか確認。
*がついているから同期されて一安心。
# ntpq -p

remote refid st t when poll reach delay offset jitter ============================================================================== *ntp1.jst.mfeed. 210.173.176.4 2 u 135 1024 377 12.078 0.781 0.267 +ntp2.jst.mfeed. 210.173.160.86 2 u 262 1024 377 11.547 0.386 0.726 +ntp3.jst.mfeed. 210.173.160.56 2 u 218 1024 377 12.929 1.080 2.694

ESXi5.0のSNMP設定

vCenterからsnmpの設定はあるが、ESXiのsnmp(trap含む）を以下に雑記する。（一部Zabbixを含む）
snmpポーリングの結果は、こちらを参照。


# cat snmp.xml
<config><snmpSettings><enable>true</enable><communities>public</communities><targets>snmpターゲットのIPアドレス@public</targets></snmpSettings></config>

#/sbin/service.sh restart

基本Zabbixトラッパーで、snmptrap監視をしているんだけどDBが255文字までしか対応していないようなので、snmptraphandleで起動するシェルの改造が必要だな・・・。

以下はmysqlのsnmptrapを受信した際に格納されるテーブルのスキーマ。（Zabbixについては時間があるときに・・・）

| history_str | CREATE TABLE `history_str` (
  `itemid` bigint(20) unsigned NOT NULL DEFAULT '0',
  `clock` int(11) NOT NULL DEFAULT '0',
  `value` varchar(255) NOT NULL DEFAULT '',　　　★ここが255文字までしかはいらない。
  KEY `history_str_1` (`itemid`,`clock`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 |



勝手にデータ型の拡張を考えている。var chare 255文字しかはいらないのは、MySQL4.1系までの仕様らしいので。


Zabbixでアイテム設定するときに、文字列型で登録していたんだけどログ型に変更したら問題なく255文字以上のログを収集することができた。

結局、history_strのvalueの型を拡張しても、255文字で切られてしまう。
またZabbixで<UNKNOWN>のメッセージがでてしまう場合があるが、これは名前解決（hostsなど）ができていないためである。

XenCenter、ライセンスサーバインストール

XenServerをインストールしたので、その後にXenCenterをインストールする。
XenServerのメディアにXenCenterも同梱されている。
メディアの自動起動でインストールを実施する。

[Next]を押す。

[Next]を押す。

[Install]を押す。

[Finish]を押して、インストール完了させる。

プログラムからXenCenterを起動する。

自動アップデートをするか警告がでるので、[No]を押す。

[Add a server]を押して、XenServerのホスト情報の入力画面を表示させる。

XenServerのIPアドレス、ログイン名、パスワードを入力する。

左メニュー欄にXenServerのホストが追加されたら完了。

XenServerのホスト名のプロパティからインポートを選択する。

インポートするファイルを指定する画面が表示される。

事前にダウンロード済みのライセンスサーバのアプライアンスを選択する。

ライセンスサーバアプライアンスのファイルが選択されていることを確認して[Next]を押す。

ファイルを展開するホストを確認し、[Next]を押す。

格納するストレージを選択して、[Next]を押す。

インポートする内容を確認して[Finish]を押す。

ライセンスサーバのインポートが開始される。

インポートが完了すると、ライセンスサーバが起動される。

コンソールタブで起動状態を確認する。

[Enter] キーを押して、次に進む。

rootの新規パスワードを入力して、[Enter] キーを押す。

domain名を入力して、[Enter] キーを押す。

IPアドレスをDHCPかStaticかどちらかを選択する。以下ではStaticなので[n]を入力して、[Enter] キーを押す。

IPアドレスを入力して、[Enter] キーを押す。

Netmaskを入力して、[Enter] キーを押す。

Gatewayを入力して、[Enter] キーを押す。

内容を確認して[y]を入力して、[Enter] キーを押す。

メニューバーの「Tools」から「License Manager」を選択する。

[Assign License]を押す。

利用するLicenseEditionを選択し、License Serverのアドレスを入力する。（ポートは27000)

Editionのフィールドに選択したLicenseEditionが表示されていれば、完了。
